rossm Posted September 10, 2015 Share Posted September 10, 2015 I have just bought the Model Alliance sheet with the Canberra retirement scheme but I'm not sure about the walkways on this aircraft - it seems they could be thick black spanwise lines with chordwise lines at the root or the 'usual' dashed red/yellow lines around the periphery of the wing. Please can anyone enlighten me? TIA, Ross Link to comment Share on other sites More sharing options...
canberra kid Posted September 10, 2015 Share Posted September 10, 2015 (edited) Hi Ross As you can see from the photo below, the walkways are a solid pail yellow line, the thick dark line is the main spar cap which in common with all latter-day Canberra's had the pain removed to aid with NDT of the spar. More PR.9 reference can be fond on my site here http://ipmscanberrasig.webs.com/apps/photos/album?albumid=12628386 John Edited September 11, 2015 by canberra kid Link to comment Share on other sites More sharing options...
canberra kid Posted September 11, 2015 Share Posted September 11, 2015 (edited) Whoops! it looks like I had posted the wrong link to my site, I've just added the right one John Edited September 11, 2015 by canberra kid Link to comment Share on other sites More sharing options...
rossm Posted September 11, 2015 Author Share Posted September 11, 2015 Thanks for the info and the photo. What is the best colour to represent the spar cap? Link to comment Share on other sites More sharing options...
canberra kid Posted September 11, 2015 Share Posted September 11, 2015 No problems Ross, your best bet for the colour for the spar cap is a dull Aluminium. John Link to comment Share on other sites More sharing options...
